Our Products
Ink Duct Film
Ink Duct Film
Ink Duct Film
Ink Duct Film
INK DUCT FILM
APPLICATION:
The Ink Duct Film is an integral part of the CPC system. It is fitted into the Ink Duct Tray. The purpose of the foil is to act as a medium between the cam system and the ink duct roller. It prevents the ink from coming into contact with the highly engineered cam system. As a consumable product, the Ink Duct Foil is designed to be disposed of at the end of each print run which enables a fast and easy color change.
APPLICATION ON: Heidelberg SM/CD 72/74, SM/CD 102, MOV, CD M/C
190 micron for Standard printing inks – per box 100 pcs.
250 micron for UV printing inks – per box 100 pcs.
TECHNICAL SPECIFICATIONS
• Translucent,
• Milky-white,
• Dimensionally stable,
• Heat resistant,
• Tear resistant,
• Water resistant.
PROTECTIVE FILM
PREMIUM
APPLICATION:
Protective Film are an extra protective polyester tape placed between the Ink Duct Foil and the ink metering cams as an insurance against the contamination of the ink duct system by seepage of the ink.
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
QUANTITY : 15 pcs per box
TECHNICAL SPECIFICATIONS:
• High bonding,
• Heat resistant,
• Tear resistant,
• Water and Chemical resistant
Protective film
Protective film
PROTECTIVE FILM
REGULAR
APPLICATION:
Protective Film are an extra protective polyester tape placed between the Ink Duct Foil and the ink metering cams as an insurance against the contamination of the ink duct system by seepage of the ink.
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
QUANTITY : 15 pcs per box
TECHNICAL SPECIFICATIONS:
• High bonding,
• Heat resistant,
• Tear resistant,
• Water and Chemical resistant
Protective Film
Protective Film
Protective Film
Protective Film
Tesamol Tape
Tesamol Tape
Tesamol Tape
Tesamol Tape
FOAM TAPE
PREMIUM
APPLICATION:
Tessamol / Foam Tape is a cellular foam placed along the bottom fold of the Ink Duct Foils to avoid seepage of excess ink into the ink metering system.
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
QUANTITY: PREMIUM - 20 pcs per box
TECHNICAL SPECIFICATIONS:
• High bonding
• Industrial grade
• Heat resistant
FOAM TAPE
REGULAR
APPLICATION:
Tessamol / Foam Tape is a cellular foam placed along the bottom fold of the Ink Duct Foils to avoid seepage of excess ink into the ink metering system.
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
QUANTITY: REGULAR - 10 meter roll.
TECHNICAL SPECIFICATIONS:
• High bonding
• Industrial grade
• Heat resistant
Tesamol Tape
Tesamol Tape
Tesamol Tape
SEALING TAPE
APPLICATION:
Sealing tape is use to fasten the Ink Duct Foil on to the duct.
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
QUANTITY: 50 pcs per box.
TECHNICAL SPECIFICATIONS:
• High bonding
• Heat resistant
ANTI MARKING NET
APPLICATION:
Anti Marking Net is use as protection medium between the Transfer cylinder and Printing sheet surface.
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
QUANTITY: 6 pcs per box.
TECHNICAL SPECIFICATIONS:
• Special coated fabric
• Long stretchable
Anti Marking Net - Super Blue
Anti Marking Net - Super Blue
Anti Marking Net - Super Blue
TRANSFER CYLINDER JACKET
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
TECHNICAL SPECIFICATIONS:
Our Glass bead film is designed and manufactured with a Triple Coated, Cross-linked ink-repellent Silicone Coating that ensures mark-free printing, is long lasting and easy to clean when required.
BRUSH WHEEL
APPLICATION:
Transporting paper. Make the paper transfer smoothly.
After the paper reaches the front gauge, stop the paper to prevent rebound.
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
TECHNICAL SPECIFICATIONS:
• Black brush feeder wheel with hard bristle
• White brush feeder wheel with soft bristle
WASH-UP BLADES
APPLICATION:
Used in cleaning the oscillating rollers in the offset printing unit before an upcoming ink change. The blade is responsible for scraping ink residues and cleaning agents from the rollers and out of the printing unit.
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
TECHNICAL SPECIFICATIONS:
• Quick wash-up performance.
• Specifically formulated rubber, plastic and other specialty materials which ensure maximum performance and wear resistance.
• Sharp and perfectly straight wiping edge.
• Specially treated metal for maximum corrosion resistance.
RUBBER SUCKERS
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
TECHNICAL SPECIFICATIONS:
• High quality material
• Dimensionally stable
• Long durability
LIFTING SUCKERS
APPLICATION ON: Heidelberg SM 72/74, SM 102, MOV, CD M/C
TECHNICAL SPECIFICATIONS:
• High quality nylon material
• Long durability
CARBON VANE
APPLICATION:
Set of rotor vanes (blades) for use in industrial vacuum pumps and compressors
TECHNICAL SPECIFICATIONS:
-
Original graphite grade
-
Precise dimensions
-
Exact vane shape
-
Efficient surface grinding (reduces the initial vane wear)
-
High temperature resistance
PLASTIC INK KNIFE
TECHNICAL SPECIFICATIONS:
• High quality plastic
• Unbreakable
QUANTITY: Set of 4 pcs.
LIQUID JELLY GREASE
TECHNICAL SPECIFICATIONS:
• Industrial grade grease.
• Liquid jelly to flow smoothly through the pipes
QUANTITY: 5KG
SCRAPPERS
TECHNICAL SPECIFICATIONS:
• Translucent,
• Milky-white,
• Dimensionally stable,
• Heat resistant,
• Tear resistant,
• Water resistant
QUANTITY: 25 pcs per box
GRIPPER
TECHNICAL SPECIFICATIONS:
• Pure Metal
• Unbreakable
• Durable
AVAILABLE FOR ALL MACHINES
Grippers
Grippers
Grippers
Grippers
Electric Card Repairing
For all printing machines
Chiller Unit
For Heidelberg Machines
Also Deals in
New and Used
Offset Printing Machines,
Paper Cutting Machine,
Carton Punching Machines
Blanket for printing machines
Calibrated Paper
Adhesive and Non Adhesive
Pneumatic cylinders for all printing machines
High Quality Grease Specially for Machine
Ink Rubber Rollers for printing machines
Yes this is ABOUT US page... but at OM CREAT we're about you.
Guaranteed Quality
Optimum Performance
Best Price
Founded in 2004, OM CREATION is India’s leading manufacture and exporter of Heildelberg pressroom consumables. Manufacturing base in Mumbai, India.
We are a team of experience, expertise, passionate and visionary people.
We offer our customers all necessary components essential to the success of their business activities in commercial and packaging printing.
We develop and produce core technologies ourselves. Our products have attained and indeed surpassed international technology and quality standards.
Our products, service offerings are tailored to meet specific future-oriented customer needs and are geared towards our customers' economic success.
